    Bolt Screw Adjustable Conventional Welding Rotator , AC Frequency Converter


    Bolt Screw Adjustable Conventional Welding Rotator , AC Frequency Converter


    1. Machine introduction

    The CWR type conventional welding rotators have advantages of the same kinds of products in domestic and international. We design and make them according to the requirments of the pressure vessel factory. These products are applied in the handling and automatic welding of the metal circle containers, they have many advantages such as advanced technology, easy operation.
    The rotators have two kinds, adjustable and conventional, it can used in all kind of the diameter and frequency conversion setting, low sound, work placidity.


    2. Technical parameters

    Type

    CWR5

    CWR10

    CWR20

    CWR30

    CWR40

    CWR50

    CWR60

    CWR80

    CWR100

    Load

    5

    10

    20

    30

    40

    50

    60

    80

    100

    Rollerl

    Metal

    roller

    Diameter

    (mm)

    240

    290

    340

    340

    390

    390

    440

    490

    490

    Width

    (mm)

    20

    25

    30

    30

    40

    40

    50

    60

    80

    Rubber

    roller

    Diameter

    (mm)

    250

    300

    350

    350

    400

    400

    450

    500

    500

    Width

    (mm)

    100

    120

    120

    120

    120

    120

    120

    120

    120

    Tube body

    diameter

    Minimum (mm)

    250

    320

    500

    530

    600

    750

    750

    850

    1000

    Maximum (mm)

    2300

    2800

    3500

    3700

    4200

    4500

    4800

    5000

    5000

    Wheel velocity (m/h)

    6-60

    6-60

    6-60

    6-60

    6-60

    6-60

    6-60

    6-60

    6-60

    Power of motor (KW)

    0.75

    1.1

    1.5

    2.2

    3

    4

    4

    4

    5.5

    Way of setting

    Electric magnetism of frequency conversion setting



    welding rotator is used to weld, polish and assemble the cylinder-shells, and to line the shells with rubber. It can be aligned according to the size of the shell, it is controlled with AC frequency converter, and the linear velocity is displayed by the digital.

    We also can design the customize various types of the welding rotator in accordance with the customers requirement.



    ● CE & ISO approved


    ● Remote control available


    ● Can be customized


    ● Import electric component


    ● Warranty:1year
