Cold Formed Steel Sections , Double Profiles C Z Purlin Roll Forming Machine

    Buy cheap Cold Formed Steel Sections , Double Profiles C Z Purlin Roll Forming Machine from wholesalers

    Buy cheap Cold Formed Steel Sections , Double Profiles C Z Purlin Roll Forming Machine from wholesalers
    • Buy cheap Cold Formed Steel Sections , Double Profiles C Z Purlin Roll Forming Machine from wholesalers

    Cold Formed Steel Sections , Double Profiles C Z Purlin Roll Forming Machine

    Ask Lasest Price
    Brand Name : FSM
    Model Number : FSM-008
    Certification : Factory certificate
    Price : 18000usd/set
    Payment Terms : Western Union, MoneyGram, L/C, T/T
    Delivery Time : 90days
    • Product Details
    • Company Profile

    Cold Formed Steel Sections , Double Profiles C Z Purlin Roll Forming Machine

    Chain Cold Formed Steel Sections , Double Profiles Roll Forming Machine


    Cold Formed Steel Sections , Double Profiles C Z Purlin Roll Forming Machine


    I: Composition of Machine

    Decoiler1 Unit
    Feeding Guide1 Unit
    Main Roll Forming1 Unit
    Cutting Device1 Unit
    Hydraulc Station1 Unit
    PLC Control Board1 Unit
    Runout Tabe2 Units

    Specifications of Profile Roof Roll Forming Machine

    Item

    Roll Forming Machine

    Coil Material

    Thickness

    0.3-0.8mm

    Coil width

    1000mm /1200mm /1250mm

    Yield Strength

    250-350 Mpa

    Material

    PPGI, Color Steel, GI.

    Decoiler

    Coil Width

    Max. 1250mm

    I.D

    508-610mm

    O.D

    Max. 1500mm

    Roll Forming Machine

    Forming Stations

    16 Stations

    Roller material

    45# steel, surface coated

    with 0.05mm hard chrome

    Diameter of shaft

    76mm

    Shaft material

    High grade 45# steel

    Drive type

    Chain transmission

    Forming speed

    0-15m/min

    Main power

    5.5KW

    Cutting

    Cutting type

    Hydraulic cutting

    Cutting power

    3KW

    CuttingTolerance

    10m+/-1.5mm

    Encoder

    OMRON Brand

    Electrical control

    PLC

    PANASONIC Brand

    Inverter

    YASKAWA Brand

    Touch screen

    PANASONICE

    Operation type

    Touch screen & Button

    Hydraulic Station

    Hydraulic station

    Famous Chinese brand

    Runout Table

    Table type

    Simple nonpower type

    Function

    To support the finished panels


    Pictures Show


    Quality Cold Formed Steel Sections , Double Profiles C Z Purlin Roll Forming Machine for sale
