    Metal Sheet CNC Drilling Machine , 1530 CNC Drilling Machine For Plate

    Ask Lasest Price
    Brand Name : Friendship Machinery
    Model Number : FSM-DBDH
    Certification : CE, ISO
    Payment Terms : L/C, T/T
    Supply Ability : 20 sets per month
    Delivery Time : 25 working days
    • Product Details
    • Company Profile

    Metal Sheet CNC Drilling Machine , 1530 CNC Drilling Machine For Plate


    Metal Sheet CNC Drilling Machine

    1530 CNC Drilling Machine For Plate

    Effective work-piece width3000mm
    Rail span4000mm
    Effective work-piece length15000mm
    Railway track18000mm
    Drive for gantry movementDouble-sided, servo driver Panasonic
    Drive for support of drilling and cutting head

    Minas A (Japan): 3 pcs.

    Servo driver Panasonic, model Minas A (Japan): 1 pcs.

    Drive of drilling head feedingReducer
    Drilling head quantity1
    Maximum drilling thickness50mm
    Cutting head quantity1
    Cutting method, flame gas

    Capacitivity sensor of height cutter monitoring

    Cutting thickness: up to 100mm

    Applicable gasesOxygen, propane
    Drilling diameter10-40mm
    Morse taperMT5
    Spindle speed0-750rpm (adjustment)
    Drill feeding speed Z-direction5-120mm/min
    Drilling head power5KW
    Maximum gantry movement speed9000mm/min
    Flame gas cutting speed50-1000mm/min
    Linear positional accuracy±0.2mm/ 10m
    Total positional accuracy±0.5mm
    Repeated positional accuracy±0.2mm
    Between adjoining holes drilling accuracy±0.2mm
    Between hole groups drilling accuracy±0.25mm
    Between any two holes drilling accuracy±0.3mm/ 15m
    CNCTNC-200 (Australia), interface language- English
    Input power40KW
