    Automatic H Beam Welding Line , H Beam Gantry Welding And Straightening Machine

    Ask Lasest Price
    Brand Name : Friendship Machinery
    Model Number : MZ
    Certification : CE, ISO
    Payment Terms : L/C, T/T
    Supply Ability : 20 sets per month
    Delivery Time : 25 working days
    • Product Details
    • Company Profile

    Automatic H Beam Welding Line , H Beam Gantry Welding And Straightening Machine

    H beam welding line - Gantry type welding machine


    ● Width of the flange: 200-800mm

    ● Thickness of the flange: 6-40mm

    ● Height of the web: 200-1800mm

    ● Thickness of the web: 6-32mm

    ● Length of the usable h beam: 4000-12000mm
    ● Welding speed: 240-1500mm/min
    ● Welding position: ship-type welding seam
    ● Size of the usable welding wire: 3.2-5mm


    H beam welding line - Hydraulic straightening machine


    ● Materials: Q235/ Q345

    ● Width of the flange: 200-800mm

    ● Maximum thickness of the flange: 60mm for Q235 and 42mm for Q345

    ● Height of the web: ≥350mm

    ● Flange yield strength: ≤235MPa

    ● Relationship between the thickness and width (materials of the work-piece: Q235)

    T6-3030-4040-5050-60
    W250-800300-800350-800400-800

    ● Note: when web has a height within 160-350mm, and flange has a thickness of less than 16mm, use straightening small-roller.

    ● Driven motor: 15KW

    ● Hydraulic system pressure: 26Mpa

    ● Press-roller/ transmission shaft: 35CrMo

    ● Power: 20.5KW


    Box beam welding line - box beam assembling machine


    H beam welding line, H beam production line
